• Like all subwoofers, careful positioning of the MartinLogan Dynamo 12 will allow you to get the best performance.

MartinLogan Dynamo 12 Technical Specifications

(reprinted from MartinLogan)

Frequency Response:
22–200 Hz ±3 dB (Anechoic via LFE input)

Low Frequency Transducer:
102 (30.5cm) high-excursion, anodized-aluminum cone in a stamped steel basket

Amplifier:
Magnitude ® MT-1.6kW Amplifier with 1,600 watts peak (800 watts continuous)

Digital Signal Processing:
Ultra High-Resolution 500MHz Vojtko DSP Engine with 64bit processing

Cabinet:
Precision-crafted, sealed MDF enclosure featuring a robust 1-inch thick MDF woofer baffle

Physical Controls:
Level: Interactive LED Backlit Knob
Tone Sweep: Sweep Start and Pause (with status light)
Power Mode: On, 12v Trigger, Auto
Wireless Audio Pairing Button (for included MartinLogan wireless transmitter)

Bluetooth Controls:
Level: -40 to 12dB (Min-Max)
Low-Pass Filter (Frequency): 35–120Hz (1° Increments)
Low-Pass Filter (Order): Bypass, Third, Fourth
Phase: 0–180° (1° Increments)
Phase (Polarity): Normal, Inverted
Preset Listening Modes: Movie, Music, Night
20–30Hz Level: ±10dB
Anthem Room Correction (ARC Genesis): On, Off
Tone Sweep (120-20Hz): On, Off, Pause (Frequency)

Inputs
Line Level: Left, Right, and LFE
XLR: LFE
Speaker Level: Left and Right (requires banana plugs)

Wireless Input:
Integrated Wireless Receiver, Wireless Transmitter Included

Feet:
Integrated Anti-Vibration Feet (carpet spikes included)

Weight:
61.5 lbs (27.9 kg)

Dimensions (HxWxD):
16-3/4" x 15-3/4" x 15-3/4"

Finish:
Gloss Black
